Modified PPO STH165-NC Resin
Place of Origin：China
Series Name：Modified PPO
Model Number：STH165-NC
Featured：Hydrolytic Stability And Good Impact Resistance
Color: Natural
Grade: Injection Molding
Application：Water Management Applications
Keywords：Modified PPO Resin/ PPO STH165-NC/ Modified STH165-NC
Material：PPO Material
Quality：High-quality
Package: 25kg/bag
Perfect Alternative: Sabic Noryl PPO 731
STH165-NC Description
Modified PPO STH165-NC resin is a non-reinforced blend of polyphenylene ether + polystyrene. This injection moldable grade exhibits high temperature resistance, chemical resistance, and good impact resistance along excellent hydrolytic stability. Modified STH165-NC resin is suitable for dyed yarn tubes and other products.
STH165-NC Datasheet
| 典型性能
Typical Property |
测试标准
ASTM |
测试条件
Test Condition |
单位
Unit |
测试值
Test Value |
| 机械性能
Mechenical |
||||
| 缺口冲击强度
lzod Notched lmpact Strength |
D256 | 23℃ | J/m | 195 |
| 无缺口冲击强度
Izod Unnotched Impact Strength |
D648 | 23℃ | J/m | / |
| 拉伸强度
Tensile Strength |
D638 | 50mm/min | Mpa | 66 |
| 断裂伸长率
Elongation at Break |
D638 | 50mm/min | % | 18 |
| 弯曲强度
Flexural Strength |
D790 | 2.8mm/min | Mpa | 100 |
| 弯曲模量
Flexural Modulus |
D790 | 2.8mm/min | Mpa | 2550 |
| 热性能
Thermal |
||||
| 热变形温度
heat deflection temperature |
D648 | 0.45Mpa | ℃ | 165 |
| 其它
Others |
||||
| 玻纤含量
Glass flber content |
ISO3451 | ％ | / | |
| 熔融指数
Melt Flow Index |
D1238 | 280℃/ 5Kg | g/10min | 3 |
| 成型收缩率
Mold Shrinkage |
D955 | % | 0.5-0.7 | |
| 密度
Density |
D792 | 23℃ | g/cm3 | 1.08 |
| 阻燃性能
flammability |
UL94 | 3.0mm | Class | HB |
More information please Contact Us ：Modified PPO STH165-NC Datasheet
Applications
Company Profile
1.Professional focus
Professional engineer service team with more than 15 years of experience; Provide a complete set of solutions and services from material sales, quality appraisal, mold design, molding and processing.
2.Perfect service
We have served many high-quality and excellent domestic and foreign enterprises, and We understand the customers’purchasing, product and service needs; From response time, price advantage, problem handling, etc., we provide comprehensive services based on customer needs in multiple dimensions.
3. Inventory supporting
Abundant inventory supporting resources, which are located in Guangzhou, Dongguan, Shenzhen free trade zone and Hong Kong. It has set up warehouses to stock goods, with a standing stock of more than 1000 tons, which can meet the timely spot purchase demand of customers and ensure the reliability and stability of the customer’s material supply chain.
4.Logistics distribution
We have long-term and stable logistics partners. According to the needs of customers, we formulate efficient istribution plans and deliver high-quality products to customers in time.
5. Speed advantage
Professional engineer service team with more than 15 years of experience; Provide a complete set of solutions and services from material sales, quality appraisal, mold design, molding and processing.
6. Small batch type selection technical support
Accept small batch orders of 5kg at least; The rofessional engineer team can cooperate with customers to carry out material selection in the early stage of production, and provide corresponding material recommendations ccording to customer production and product requirements
7. Quality assurance
Our products are all from well-known manufacturers. Each batch of materials has various inspection reports and certificates including original factory certificate, MSDS, ROHS, SGS, reach,, EU, UL, COC / COA, etc.
