Modified PPO STSNG20V Resin
Place of Origin：China
Series Name：Modified PPO
Model Number：STSNG20V
Featured：Flame Retardant, High Impact, Dimensional Stability
Color: Black
Grade: Injection Molding
Application：New Energy Vehicle Battery Box
Keywords：Modified PPO Resin/ PPO STSNG20V/ Modified STSNG20V
Material：PPO Material
Quality：High-quality
Package: 25kg/bag
Perfect Alternative: Sabic Noryl PPO Resin
STSNG20V Description
Modified STSNG20V is a grade of PPO resin that is designed for high flow and excellent impact resistance. This material is known for its good dimensional stability, low moisture absorption, and flame retardant UL94-V0 resistance to a wide range of chemicals. It is often utilized in applications within for new energy vehicle battery box.
STSNG20V Datasheet
| 典型性能
Typical Property |
测试标准
ASTM |
测试条件
Test Condition |
单位
Unit |
测试值
Test Value |
| 机械性能
Mechenical |
||||
| 缺口冲击强度
lzod Notched lmpact Strength |
D256 | 23℃ | J/m | 90.6 |
| 无缺口冲击强度
Izod Unnotched Impact Strength |
D648 | 23℃ | J/m | 344 |
| 拉伸强度
Tensile Strength |
D638 | 50mm/min | Mpa | 90 |
| 断裂伸长率
Elongation at Break |
D638 | 50mm/min | % | / |
| 弯曲强度
Flexural Strength |
D790 | 2.8mm/min | Mpa | 133 |
| 弯曲模量
Flexural Modulus |
D790 | 2.8mm/min | Mpa | 5122 |
| 热性能
Thermal |
||||
| 热变形温度
heat deflection temperature |
D648 | 0.45Mpa | ℃ | 128 |
| 其它
Others |
||||
| 玻纤含量
Glass flber content |
ISO3451 | ％ | 20 | |
| 熔融指数
Melt Flow Index |
D1238 | 280℃/ 5Kg | g/10min | 12 |
| 成型收缩率
Mold Shrinkage |
D955 | % | 0.3-0.4 | |
| 密度
Density |
D792 | 23℃ | g/cm3 | 1.22 |
| 阻燃性能
flammability |
UL94 | 2mm | Class | V0 |
More information please Contact Us ：Modified PPO STSNG20V Datasheet
