Samtion STRNH6606 PA66 Resin Halogen-free Flame Retardant 30%GF Injection Molding Used For Electronic Components

Samtion STRNH6606 resin is a 30%GF(Glass Fiber Reinforced) polyamide 66 resin for injection molding. This resin is a Halogen-free Flame Retardant Material, and it is common used for electronic components.

Common Applications

Samtion PA66 STRNH6606

Place of Origin:China
Brand Name:Samtion
Model Number:STRNH6606
Featured:30%GF and Halogen-free Flame Retardant
Color: Natural, Black
Grade: Injection Molding Grade
Application:Electronic Components
Keywords:Samtion PA66/ Samtion STRNH6606/ PA66 STRNH6606
Material:PA66 Material Resin
Quality:High-quality
Package: 25kg/bag
Perfect alternative: Toray PA66 HF3064G-30, Akulon SG-KGS6, Leona FH772, Basf Ultramid A3UG5

STRNH6606 Description

PA66, also known as polyamide 66 or nylon 66, is a type of synthetic polymer belonging to the nylon family. It is a versatile material known for its high strength, rigidity, and thermal resistance. PA66 is used in various applications, including automotive components, electrical insulators, engineering plastics, and consumer goods.

This material offers excellent mechanical properties, good resistance to heat and chemicals, and is often chosen for its durability and reliability in demanding environments. Its inherent properties make it suitable for use in a wide range of industries, including automotive, electronics, industrial manufacturing, and consumer goods. PA66 can be found in products such as gears, bearings, electrical connectors, cable ties, and various structural components.

PA66 is commonly used in the production of injection-molded parts and is valued for its balance of mechanical strength, impact resistance, and resistance to wear and abrasion. It can also be reinforced with various additives such as glass fibers to further enhance its mechanical properties, making it a preferred material for a wide array of engineering applications.

Samtion STRNH6606 resin is a 30%GF(Glass Fiber Reinforced) polyamide 66 resin for injection molding. This resin is a Halogen-free Flame Retardant Material, and it is common used for electronic components.


Samtion STRNH6606 is a Halogen-free flame retardant PA66 (nylon 66) Material without phosphorus. This type of resin make itself important for reducing the environmental and health concerns associated with traditional halogen-containing flame retardants. These alternatives are designed to meet the flammability requirements while avoiding the use of halogens like bromine and chlorine.

It’s important to consider the specific requirements and regulations for the application of flame-retardant PA66 in various industries, such as automotive, electrical, and electronics, to ensure that the chosen halogen-free flame retardant meets the necessary standards for performance, safety, and environmental impact.



PA66 Datasheet

Test ItemsTesting StandardsUnit

PA66 ST3004

Halogen Free Flame Retardant

PA66 STRNH6605

Halogen-Free Flame Retardant Reinforcement

PA66 ST201FR

Australian Flame Retardant

ProportionASTM D792g/cm³1.1981.361.38
Shore HardnessASTM D2240HD818580
Tensile StrengthASTM D638MPa7213050
Elongation at BreakASTM D638%53.55
Bending StrengthASTM D790MPa11520385
Flexural ModulusASTM D790MPa310072502800
Impact Strength of Cantilever Beam NotchASTM D256KJ/㎡3.2125
Melting PointASTM D4591242245245
Recommended Drying TemperatureQCS80-9080-9080-90
Recommended Drying TimeQCSH3-44-53-4
Suggested Injection TemperatureQCS250-270260-270255-270

Data Sheet one

Test ItemsTesting StandardsUnit

PA66 ST201G30

Australican Flame Retardant Reinforcement

PA66 ST101G30

Glass Fiber Reinforced

PA66 STR2000HS

Toughened and Cold Resistant

ProportionASTM D792g/cm³1.61.381.1
Shore HardnessASTM D2240HD848478
Tensile StrengthASTM D638MPa12016560
Elongation at BreakASTM D638%2.5450
Bending StrengthASTM D790MPa19525588
Flexural ModulusASTM D790MPa825082502000
Impact Strength of Cantilever Beam NotchASTM D256KJ/㎡111316
Melting PointASTM D4591240250240
Recommended Drying TemperatureQCS80-9080-9080-90
Recommended Drying TimeQCSH3-43-44-5
Suggested Injection TemperatureQCS250-270270-290250-270
Data Sheet Two

More information please Contact Us :Samtion PA66 STRNH6606 Datasheet


Company Profile

1.Professional focus
Professional engineer service team with more than 15 years of experience; Provide a complete set of solutions and services from material sales, quality appraisal, mold design, molding and processing.
2.Perfect service
We have served many high-quality and excellent domestic and foreign enterprises, and We understand the customers’purchasing, product and service needs; From response time, price advantage, problem handling, etc., we provide comprehensive services based on customer needs in multiple dimensions.
3. Inventory supporting
Abundant inventory supporting resources, which are located in Guangzhou, Dongguan, Shenzhen free trade zone and Hong Kong. It has set up warehouses to stock goods, with a standing stock of more than 1000 tons, which can meet the timely spot purchase demand of customers and ensure the reliability and stability of the customer’s material supply chain.
4.Logistics distribution
We have long-term and stable logistics partners. According to the needs of customers, we formulate efficient istribution plans and deliver high-quality products to customers in time.
5. Speed advantage
Professional engineer service team with more than 15 years of experience; Provide a complete set of solutions and services from material sales, quality appraisal, mold design, molding and processing.
6. Small batch type selection technical support
Accept small batch orders of 5kg at least; The rofessional engineer team can cooperate with customers to carry out material selection in the early stage of production, and provide corresponding material recommendations ccording to customer production and product requirements
7. Quality assurance
Our products are all from well-known manufacturers. Each batch of materials has various inspection reports and certificates including original factory certificate, MSDS, ROHS, SGS, reach,, EU, UL, COC / COA, etc.
3
Weight 25 kg
Dimensions 60 × 45 × 15 cm
Brand

Series

PA6/PA66

Model Number

ST3004

Non-Brominated

Non-Chlorinated

UL94 Flame Class

Glass Fiber Reinforced
