Modified PPO STHG20 Resin Granules For Fluid Engineering Applications 20% GF UV Stabilized Hydrolytic Stability

Modified PPO STHG20 resin is a 20% glass fiber reinforced blend of polyphenylene ether (PPE) + polystyrene (PS). This general-purpose injection moldable grade exhibits very low moisture absorption, high strength, hydrolytic stability, Low warpage, low specific gravity, and dimensional stability. STHG20 carries a UL746C outdoor suitability rating of F1 and is an excellent candidate for a variety of fluid engineering applications.

Category: Tags: , , , ,
Click here For The Best Price/Samples/PDF Datasheets

Modified PPO STHG20 Resin

Place of Origin：China
Series Name：Modified PPO
Model Number：STHG20
Featured：20% Glass Fiber Reinforced, UV Stabilezed, Hydrolytic Stability
Color: STHG20-NC(Natural), STHG20-BK(Black) STHG20-780(Gray)
Grade: Injection Molding
Application：Fluid Engineering Applications
Keywords：Modified PPO Resin/ PPO STHG20/ Modified STHG20
Material：PPO Material
Quality：High-quality
Package: 25kg/bag
Perfect Alternative: Sabic Noryl PPO GFN2

STHG20 Description

Modified PPO STHG20 resin is a 20% glass fiber reinforced blend of polyphenylene ether (PPE) + polystyrene (PS). This general-purpose injection moldable grade exhibits very low moisture absorption, high strength, hydrolytic stability, Low warpage, low specific gravity, and dimensional stability. STHG20 carries a UL746C outdoor suitability rating of F1 and is an excellent candidate for a variety of electrical components and fluid engineering applications.

STHG20-NC Datasheet

典型性能

Typical Property

 测试标准

ASTM

 测试条件

Test Condition

 单位

Unit

 测试值

Test Value
机械性能

Mechenical
缺口冲击强度

lzod Notched lmpact Strength

 D256 23℃ J/m 149
无缺口冲击强度

Izod Unnotched Impact Strength

 D648 23℃ J/m 490
拉伸强度

Tensile Strength

 D638 50mm/min Mpa 104
断裂伸长率

Elongation at Break

 D638 50mm/min % /
弯曲强度

Flexural  Strength

 D790 2.8mm/min Mpa 145
弯曲模量

Flexural Modulus

 D790 2.8mm/min Mpa 5240
热性能

Thermal
热变形温度

heat deflection temperature

 D648 0.45Mpa ℃ 139
其它

Others
玻纤含量

Glass flber content

 ISO3451 ％ 20
熔融指数

Melt Flow Index

 D1238 280℃/ 5Kg g/10min 8
成型收缩率

Mold Shrinkage

 D955 % 0.2-0.4
密度

Density

 D792 23℃ g/cm3 1.21
阻燃性能

flammability

 UL94 3.0mm Class HB

STHG20-BK Datasheet

典型性能

Typical Property

 测试标准

ASTM

 测试条件

Test Condition

 单位

Unit

 测试值

Test Value
机械性能

Mechenical
缺口冲击强度

lzod Notched lmpact Strength

 D256 23℃ J/m 138
无缺口冲击强度

Izod Unnotched Impact Strength

 D648 23℃ J/m 461
拉伸强度

Tensile Strength

 D638 50mm/min Mpa 94.1
断裂伸长率

Elongation at Break

 D638 50mm/min % /
弯曲强度

Flexural  Strength

 D790 2.8mm/min Mpa 146.8
弯曲模量

Flexural Modulus

 D790 2.8mm/min Mpa 5510
热性能

Thermal
热变形温度

heat deflection temperature

 D648 0.45Mpa ℃ 139
其它

Others
玻纤含量

Glass flber content

 ISO3451 ％ 20
熔融指数

Melt Flow Index

 D1238 280℃/ 5Kg g/10min 8.6
成型收缩率

Mold Shrinkage

 D955 % 0.2-0.4
密度

Density

 D792 23℃ g/cm3 1.22
阻燃性能

flammability

 UL94 3.0mm Class HB

STHG20-780 Datasheet

典型性能

Typical Property

 测试标准

ASTM

 测试条件

Test Condition

 单位

Unit

 测试值

Test Value
机械性能

Mechenical


缺口冲击强度

lzod Notched lmpact Strength

 D256 23℃ J/m 138
无缺口冲击强度

Izod Unnotched Impact Strength

 D648 23℃ J/m 484
拉伸强度

Tensile Strength

 D638 50mm/min Mpa 94
断裂伸长率

Elongation at Break

 D638 50mm/min % /
弯曲强度

Flexural  Strength

 D790 2.8mm/min Mpa 141
弯曲模量

Flexural Modulus

 D790 2.8mm/min Mpa 4797
热性能

Thermal


热变形温度

heat deflection temperature

 D648 0.45Mpa ℃ 134
其它

Others


玻纤含量

Glass flber content

 ISO3451   ％ 20
熔融指数

Melt Flow Index

 D1238 280℃/ 5Kg g/10min 8.7
成型收缩率

Mold Shrinkage

 D955   % 0.2-0.4
密度

Density

 D792 23℃ g/cm3 1.22
阻燃性能

flammability

 UL94 3.0mm Class HB
More information please Contact Us ：Modified PPO STHG20 Datasheet
