Sabic Lexan PC 3412R 20% GR, Provides Improved Mechanical Properties And UL94 V-1 Rated At 0.058″ Mold Release.

Sabic Lexan PC3412R resin is a 20% glass fiber filled, 4.3 MFR polycarbonate, MVR of 6. Mold release. Flame retardant, UL94 V0 and 5VA rated. Available in natural and opaque colors. It provides improved mechanical properties.

SKU: sabic0052 Category: Tags: , ,

Sabic Lexan PC 3412R Description

Sabic Lexan PC3412R resin is a 20% glass fiber filled, 4.3 MFR polycarbonate, MVR of 6. Mold release. Flame retardant, UL94 V0 and 5VA rated. Available in natural and opaque colors. It provides improved mechanical properties.   SABIC lexan PC features :

  1. Impact resistance Has the highest impact strength values among plastics and is higher than cast zinc and cast aluminum
  2. The operating temperature range can maintain stable characteristics over a wide range of low to high temperatures (-100 °C ~ 129 °C).
  3. Electrical properties Excellent electrical insulation properties over a wide temperature range
  4. Transparency It has a slight transparency of plastics and is suitable for optical and sheet applications.
  5. Dimensional stability With excellent creep resistance, the size is almost unaffected by moisture absorption, temperature, and time changes
  6. Flame retardancy.It has excellent flame retardancy and has passed the V-0, V-1, V-2, HB, 5VA, and 5VB ratings of UL subject94

datasheet tittle

Properties

MECHANICAL Value Unit Standard
Tensile Stress, brk, Type I, 5 mm/min 110 MPa ASTM D 638
Tensile Strain, brk, Type I, 5 mm/min 5 % ASTM D 638
Flexural Stress, yld, 1.3 mm/min, 50 mm span 131 MPa ASTM D 790
Flexural Modulus, 1.3 mm/min, 50 mm span 5510 MPa ASTM D 790
Hardness, Rockwell M 91 ASTM D 785
Hardness, Rockwell R 122 ASTM D 785
Taber Abrasion, CS-17, 1 kg 17 mg/1000cy ASTM D 1044
IMPACT Value Unit Standard
Izod Impact, unnotched, 23°C 1014 J/m ASTM D 4812
Izod Impact, notched, 23°C 106 J/m ASTM D 256
Tensile Impact, Type “S” 63 kJ/m² ASTM D 1822
Falling Dart Impact (D 3029), 23°C 5 J ASTM D 3029
THERMAL Value Unit Standard
Vicat Softening Temp, Rate B/50 165 °C ASTM D 1525
HDT, 0.45 MPa, 6.4 mm, unannealed 148 °C ASTM D 648
HDT, 1.82 MPa, 6.4 mm, unannealed 146 °C ASTM D 648
CTE, -40°C to 95°C, flow 2.7E-05 1/°C ASTM E 831
Specific Heat 1.17 J/g-°C ASTM C 351
Thermal Conductivity 0.21 W/m-°C ASTM C 177
Relative Temp Index, Elec 130 °C UL 746B
Relative Temp Index, Mech w/impact 130 °C UL 746B
Relative Temp Index, Mech w/o impact 130 °C UL 746B
PHYSICAL Value Unit Standard
Specific Gravity 1.35 ASTM D 792
Specific Volume 0.74 cm³/g ASTM D 792
Density 1.356 g/cm³ ASTM D 792
Water Absorption, 24 hours 0.16 % ASTM D 570
Water Absorption, equilibrium, 23C 0.29 % ASTM D 570
Mold Shrinkage, flow, 3.2 mm 0.1 – 0.3 % SABIC Method
Melt Flow Rate, 300°C/1.2 kgf 4.3 g/10 min ASTM D 1238
ELECTRICAL Value Unit Standard
Volume Resistivity >1.E+17 Ohm-cm ASTM D 257
Dielectric Strength, in air, 3.2 mm 19.2 kV/mm ASTM D 149
Relative Permittivity, 50/60 Hz 3.17 ASTM D 150
Relative Permittivity, 1 MHz 3.13 ASTM D 150
Dissipation Factor, 50/60 Hz 0.0009 ASTM D 150
Dissipation Factor, 1 MHz 0.0073 ASTM D 150
Arc Resistance, Tungsten {PLC} 7 PLC Code ASTM D 495
Hot Wire Ignition {PLC) 0 PLC Code UL 746A
High Voltage Arc Track Rate {PLC} 3 PLC Code UL 746A
High Ampere Arc Ign, surface {PLC} 4 PLC Code UL 746A
Comparative Tracking Index (UL) {PLC} 5 PLC Code UL 746A
FLAME CHARACTERISTICS Value Unit Standard
UL Recognized, 94V-1 Flame Class Rating (3) 1.47 mm UL 94
UL Recognized, 94V-0 Flame Class Rating (3) 2.99 mm UL 94
UL Recognized, 94-5VA Rating (3) 2.99 mm UL 94
Source GMD, last updated:06/27/2002

Processing

Injection Molding Value Unit
Drying Temperature 120 °C
Drying Time 3 – 4 hrs
Drying Time (Cumulative) 48 hrs
Maximum Moisture Content 0.02 %
Melt Temperature 315 – 340 °C
Nozzle Temperature 310 – 330 °C
Front – Zone 3 Temperature 315 – 340 °C
Middle – Zone 2 Temperature 305 – 325 °C
Rear – Zone 1 Temperature 295 – 315 °C
Mold Temperature 80 – 115 °C
Back Pressure 0.3 – 0.7 MPa
Screw Speed 40 – 70 rpm
Shot to Cylinder Size 40 – 60 %
Vent Depth 0.025 – 0.076 mm
Source GMD, last updated:06/27/2002

For more information please download the datasheet

PDF File

Sabic Lexan 3412R

Company Profile



1.Professional focus
Professional engineer service team with more than 15 years of experience; Provide a complete set of solutions and services from material sales, quality appraisal, mold design, molding and processing.
2.Perfect service
We have served many high-quality and excellent domestic and foreign enterprises, and We understand the customers’purchasing, product and service needs; From response time, price advantage, problem handling, etc., we provide comprehensive services based on customer needs in multiple dimensions.
3. Inventory supporting
Abundant inventory supporting resources, which are located in Guangzhou, Dongguan, Shenzhen free trade zone and Hong Kong. It has set up warehouses to stock goods, with a standing stock of more than 1000 tons, which can meet the timely spot purchase demand of customers and ensure the reliability and stability of the customer’s material supply chain.
4.Logistics distribution
We have long-term and stable logistics partners. According to the needs of customers, we formulate efficient istribution plans and deliver high-quality products to customers in time.
5. Speed advantage
Professional engineer service team with more than 15 years of experience; Provide a complete set of solutions and services from material sales, quality appraisal, mold design, molding and processing.
6. Small batch type selection technical support
Accept small batch orders of 5kg at least; The rofessional engineer team can cooperate with customers to carry out material selection in the early stage of production, and provide corresponding material recommendations ccording to customer production and product requirements
7. Quality assurance
Our products are all from well-known manufacturers. Each batch of materials has various inspection reports and certificates including original factory certificate, MSDS, ROHS, SGS, reach,, EU, UL, COC / COA, etc.

24 hours working
Weight 25 kg
Dimensions 60 × 45 × 15 cm
Brand

Sabic

Model Number

3412R

Series

Lexan

Melt Flow Rate

Mold Release

Internal

Color

Natural And Opaque

UL94 Flame Class

Glass Fiber Reinforced
